Zeolites have long been considered the backbone of catalytic processes in petrochemical and refining industries. Among the diverse family of zeolites, medium-pore zeolites (such as ZSM-5, ZSM-11, and MCM-22) have been widely employed due to their versatility, thermal stability, and tunable acidity. However, as industrial applications demand increasingly precise control over diffusion and product selectivity, the limitations of conventional medium-pore zeolites have become apparent.
This is where ZSM-22 (TON framework) enters the discussion. ZSM-22 is a high-silica, medium-pore zeolite with a unique one-dimensional 10-membered ring (10-MR) channel system. Unlike the more commonly used ZSM-5, which has a three-dimensional pore network, ZSM-22’s strictly one-dimensional channels impose different diffusion constraints. These differences significantly affect catalytic performance, particularly in processes such as hydroisomerization of linear paraffins, where selectivity and coke resistance are critical.
This article explores the trade-off between diffusion and selectivity when comparing medium-pore zeolites with ZSM-22, drawing on academic studies, industrial applications, and experimental insights.
Medium-pore zeolites are defined by pore openings of about 5.3–6.0 Å, typically formed by 10-membered rings. Common representatives include:
ZSM-5 (MFI framework): 3D interconnected pore system, widely used in FCC gasoline upgrading and methanol-to-hydrocarbon (MTH) reactions.
ZSM-11 (MEL framework): Similar to ZSM-5, but with different pore connectivity.
MCM-22 (MWW framework): Features a 2D sinusoidal pore system and large supercages.
High versatility across refining and petrochemical processes.
Balanced diffusion and product diversity.
Well-studied, with decades of industrial data.
Diffusion limitations: 3D networks can promote secondary reactions.
Selectivity challenges: Aromatization and cracking side reactions can lower target yields.
Coking: Larger pore intersections can promote coke formation, reducing catalyst life.
ZSM-22 is part of the TON topology family, with a highly distinctive one-dimensional pore system.
Pore size: ~5.5 Å (10-membered ring channels).
Channel system: Linear, unidirectional, with no intersections.
Si/Al ratio: Flexible, allowing acidity tuning.
High Shape Selectivity:
The linear, non-intersecting channels suppress undesired secondary reactions.
Resistance to Coking:
The narrow, one-dimensional channels limit large polyaromatic formation, extending catalyst life.
Specialized in Hydroisomerization:
ZSM-22 has shown excellent performance in n-alkane hydroisomerization, delivering higher selectivity toward mono-branched isomers, which are desirable for fuel quality.
Corma et al., Journal of Catalysis, 1984: Demonstrated ZSM-22’s superior selectivity in n-decane isomerization compared to ZSM-5.
Martens & Jacobs, Applied Catalysis A, 1999: Reported that ZSM-22 resists deactivation better under hydroisomerization conditions.
Diffusion: Multidimensional pore systems allow faster transport of molecules but increase chances for secondary reactions (e.g., cracking, aromatization).
Selectivity: Broader pore access means less control over product distribution.
Diffusion: Restricted by one-dimensional channels, which may slow reactant/product transport. This can reduce overall activity at high conversion.
Selectivity: Strongly improved, because molecules undergo fewer unwanted side reactions.
The trade-off is clear:
Medium-pore zeolites → better throughput, but lower selectivity and higher coking.
ZSM-22 → lower throughput, but higher selectivity and longer catalyst life.
For refinery operators, the decision depends on whether the priority is maximizing yield per hour (throughput) or maximizing the value of specific products (selectivity).
Hydroisomerization is a key refining process for improving fuel quality.
With ZSM-5 (MFI): Tends to produce branched isomers but also significant cracking to light gases, lowering liquid yield.
With ZSM-22 (TON): Strong shape selectivity favors mono-branched isomers with minimal cracking, directly enhancing cetane number and cold flow properties in diesel fuels.
Reference: “Hydroisomerization of n-alkanes on ZSM-22,” Corma & Martínez, Catalysis Reviews, 1993.
ZSM-22 Composite Catalysts: Combination with amorphous supports or bifunctional metals (Pt/ZSM-22) enhances hydrogenation–isomerization synergy.
Hierarchical ZSM-22: Introducing mesopores to improve diffusion while retaining 1D selectivity.
Industrial Testing: New diesel and lubricants formulations increasingly explore TON-type catalysts for fuel optimization.
When to Choose Medium-Pore Zeolites:
When feedstock diversity is high.
When throughput is prioritized over selectivity.
When to Choose ZSM-22:
When paraffin isomerization is the main target.
When coke resistance and longer cycle lengths are critical.
Q1: What is the main difference between ZSM-22 and ZSM-5?
A: ZSM-22 has one-dimensional channels with no intersections, while ZSM-5 has a 3D interconnected pore system. This makes ZSM-22 more selective but less diffusive.
Q2: Is ZSM-22 commercially available for large-scale refining?
A: Yes, ZSM-22 has been tested and used in commercial hydroisomerization units, particularly in Europe and Asia, often as part of bifunctional catalysts with metals like platinum.
Q3: Can ZSM-22 completely replace medium-pore zeolites?
A: Not entirely. Medium-pore zeolites remain versatile for a broad range of feedstocks. ZSM-22 is best suited for specialized applications requiring high selectivity.
Q4: Does ZSM-22 have limitations?
A: Its one-dimensional channels can lead to diffusional restrictions and lower activity under high loadings, which researchers are addressing with hierarchical structures.
Q5: How does ZSM-22 improve fuel properties?
A: By selectively producing mono-branched paraffins during hydroisomerization, ZSM-22 helps improve cold flow properties and cetane number in diesel fuels.
