The refining industry stands at a crossroads. As global demand shifts towards cleaner fuels, better efficiency, and stricter environmental compliance, traditional catalyst systems are being pushed to their limits. One of the persistent challenges in refining is the isomerization of long-chain n-paraffins into branched isomers that deliver improved cold flow properties and higher octane values.
Enter ZSM-22, a member of the TON framework family of zeolites. Its one-dimensional 10-membered ring channels make it uniquely suited for paraffin isomerization, providing high selectivity, reduced coke formation, and longer catalyst life. In this article, we will explore why ZSM-22 is increasingly indispensable in refining, its role in addressing pain points, and its future opportunities across fuels and specialty chemicals.
Modern refineries must balance multiple pressures:
Environmental Regulations: Euro VI, IMO, and EPA standards mandate low-sulfur, high-performance fuels.
Market Shifts: Growing demand for low-pour-point diesel, aviation fuels, and high-octane gasoline.
Operational Costs: Catalyst deactivation, regeneration, and downtime significantly impact profitability.
n-Paraffin isomerization sits at the center of this. Straight-chain paraffins have poor cold-flow properties, making them unsuitable for diesel or jet fuels in cold climates. Converting these molecules into monobranched isomers improves fuel usability without significant yield loss.
Traditional catalysts (such as Pt/ZSM-5 or amorphous silica-alumina) can perform the transformation but often suffer from:
Excessive cracking → reduced yield.
Poor selectivity → unwanted by-products.
Coke formation → frequent regeneration.
This is where ZSM-22 demonstrates clear advantages.
ZSM-22 was first reported in 1982 and has since gained recognition for its unique one-dimensional pore architecture:
Channel dimensions: ~0.45 × 0.55 nm.
Topology: TON framework with straight 10-membered channels.
Absence of intersections: Unlike ZSM-5, ZSM-22 avoids channel congestion.
High Si/Al ratios: Enables fine-tuning of acidity and catalytic strength.
These properties lead to:
Selective diffusion of linear molecules → ideal for n-paraffins.
Reduced secondary reactions → fewer aromatics and heavy by-products.
Improved stability under hydrothermal conditions.
In essence, ZSM-22 provides the shape-selectivity and efficiency that isomerization units have long sought.
Problem: ZSM-5’s 3D pore network often traps intermediates, slowing reactions and encouraging side-reactions.
ZSM-22 Advantage: Straight channels provide a direct pathway, enhancing diffusion and minimizing unwanted transformations.
Problem: Balancing cracking and isomerization is difficult, often leading to excessive light gas production.
ZSM-22 Advantage: ZSM-22’s narrow pores favor monobranched isomers—the sweet spot for cold-flow performance—while suppressing deep cracking.
Problem: Coke deposition deactivates catalysts prematurely.
ZSM-22 Advantage: Reduced secondary reactions lead to less coke, extending operational cycles and lowering regeneration costs.
Problem: Refiners need catalysts aligned with ultra-low sulfur fuel requirements and green initiatives.
ZSM-22 Advantage: By enabling efficient hydroisomerization, ZSM-22 helps meet cold-flow and octane standards without compromising yield.
ZSM-22-based catalysts improve cold flow properties by producing monobranched isomers. This directly impacts the usability of fuels in cold regions and helps refiners meet stringent pour-point specifications.
By converting linear paraffins into branched isomers, ZSM-22 contributes to octane upgrading without excessive cracking—crucial in balancing refinery economics.
ZSM-22 enables the production of high-quality base oils with improved viscosity index and thermal stability, essential for automotive and industrial lubricants.
Emerging research suggests ZSM-22 can play a role in biomass-to-fuel processes and sustainable hydrocarbon synthesis, reinforcing its long-term relevance.
Corma et al. (1994, Journal of Catalysis): Demonstrated ZSM-22’s superior selectivity in hydroisomerization compared to ZSM-5, with reduced cracking and enhanced stability.
Raeissi et al. (Applied Catalysis A, 2008): Showed that ZSM-22 catalysts extended operational lifetimes due to reduced coke deposition.
Recent patents (Shell, ExxonMobil): Highlight industrial adoption of ZSM-22 in diesel upgrading units for better cold-flow properties.
These studies underscore the real-world validation of ZSM-22’s performance.
| Property | ZSM-5 (MFI) | ZSM-22 (TON) | SAPO-11 |
|---|---|---|---|
| Pore System | 3D, intersecting | 1D, straight | 1D, elliptical |
| Diffusion Limitations | Moderate–High | Low | Low |
| Selectivity (isomerization) | Medium | High | Medium |
| Coke Resistance | Moderate | High | Moderate |
| Best Applications | Aromatization, cracking | Isomerization, diesel | Hydroisomerization |
This comparison shows ZSM-22 as a specialist catalyst, excelling in selective isomerization of n-paraffins.
Sustainability Push: Low-carbon fuels require catalysts that maximize efficiency with minimal waste.
EV Transition: While EVs reduce gasoline demand, diesel and aviation fuels remain critical, requiring advanced catalysts like ZSM-22.
Customization Potential: Variations in Si/Al ratio, crystal morphology, and metal promotion (Pt/ZSM-22) expand applicability.
Our company will soon introduce a new product line of ZSM-22 catalysts, designed to meet diverse refining requirements and tailored for isomerization, base oil production, and sustainable fuels.
ZSM-22 represents a strategic solution to modern refining challenges. Its one-dimensional TON framework solves diffusion and selectivity trade-offs, delivering higher yields, cleaner fuels, and longer catalyst lifetimes.
As the refining industry evolves, ZSM-22 is positioned not just as another zeolite, but as a cornerstone catalyst that supports efficiency, profitability, and sustainability.
Q1: Why is ZSM-22 better for paraffin isomerization than ZSM-5?
ZSM-5 has a 3D pore system prone to diffusion bottlenecks, while ZSM-22’s 1D straight channels enhance diffusion and selectivity for linear molecules.
Q2: What makes ZSM-22 environmentally relevant?
It produces fuels with improved cold-flow properties and lower by-product formation, aligning with stricter fuel standards and sustainability goals.
Q3: Can ZSM-22 catalysts be regenerated?
Yes. Thanks to reduced coke deposition, ZSM-22 catalysts require less frequent regeneration, lowering operational costs.
Q4: How does ZSM-22 compare with SAPO-11?
Both are one-dimensional, but ZSM-22 offers higher stability and selectivity in n-paraffin isomerization.
Q5: Will your company provide ZSM-22 products soon?
Yes. We are preparing to launch customized ZSM-22 catalysts with tunable properties for refining and petrochemical industries.
Q6: Does ZSM-22 have applications beyond fuels?
Yes. It shows promise in lubricant base oils, fine chemicals, and biomass conversion, making it versatile across industries.
